Disc granulator is an important equipment in pan granulator production line. It is suitable for both organic fertilizer production and compound fertilizer production. Its granulation rate can achieve 93%. Even though these pan granulators with different models (they are different on diameters, auxiliary device equipped and side height.), all of them have good performance on operation, granulation and service life.
Compact structure: Its main parts include granulation disc, reducer, motor, pedestal and scraper device. The inner part of disc adopts special materials and its bottom adopt multiple radiation steel plates, which can make disc get rid of deformation. The reducer and motor are connected by flexible belt drive. The pedestal adopts thickened and aggravated, which can provide steady support for the whole machine.
Working process and principle: Organic manure enters granulator form the inner part. With the rotating of disc and involvement of water, the powder gradually become pellets. At the same time, the scraper device will clear materials that stick to the bottom of disc. When the disc rotates, water and centrifugal force will make powder become pellets. In addition, the tilt of disc is adjustable. Smaller tilt and less moisture will make smaller pellets, vice versa.
Code | Disc Dia. (mm) | Disk Depth,(mm) | Volume(m3) | Rotary Speed,r/min | Power(KW) | Ouput(t/h) |
ZJ25 | 2500 | 500 | 2.5 | 13.6 | 7.5 | 1-2 |
ZJ28 | 2800 | 600 | 3.7 | 13.6 | 11 | 2-3 |
ZJ30 | 3000 | 600 | 4.2 | 13.6 | 11 | 2-4 |
ZJ32 | 3200 | 600 | 4.8 | 13.6 | 15 | 3-5 |
ZJ45 | 4500 | 600 | 6.1 | 12.28 | 30 | 8-10 |
