Rotary drum granulator is also available for organic fertilizer and compound fertilizer production. It consists of bracket, driving part, rolling belt, gear and machine body.
Rotary drum granulator is also available for organic fertilizer and compound fertilizer production. It consists of bracket, driving part, rolling belt, gear and machine body. The driving part provides power for the rotation of main body. The machine body provides a good environment for granulation. Convey belt sends raw materials to the granulator. With the rotation of main body and the involvement of water, powdery manure agglomerate into small particles. Then, these particles will slowly move to the other end along the tilt of granulator. During this process, small particles gradually becomes spherical pellets. Generally speaking, the inner part of main body is usually lined with PVC plastic plate or stainless-steel plate, so as to effectively prevent adhesion. Its granulation rate can reach 70%, which means less returning fertilizer with small size.
| Code | Drum dip angle | Drum Dia. m | length | Rotary Speed, r/min | Power,KW | Capacity, t/h | Size, L*W*H | Weight, T |
| ZG1.2*6 | 2-2.5 | 1.2 | 6 | 14 | 7.5 | 3-4 | 6.6*1.8*1.8 | 6.5 |
| ZG1.5*6 | 2-2.5 | 1.5 | 6 | 12 | 11 | 4-7 | 6.8*2.2*2.0 | 8.5 |
| ZG1.8*7 | 2-2.5 | 1.8 | 7 | 11.5 | 15 | 8-10 | 8.3*3.5*3.3 | 13 |
| ZG2.0*8 | 2-2.5 | 2.0 | 8 | 11 | 18.5 | 10-15 | 9.1*3.6*3.5 | 18 |
